HARDWARE INSTALLATION
2.4.6 Wake-on-LAN Connector (3-pin WOL)
This connector connects to LAN cards with a Wake-on-LAN output. The system can be Powered
Up when a wake-up packet or signal is received from the LAN card.
NOTE: This function requires that the “Wake-Up by PCI & WOL” function in the “Power
Management Setup” in BIOS is set to “Enabled” and that your system has an ATX power
supply with at least 720mA +5V standby power.
+ 5 V S t a n d b y
Wake-on-LAN Connector
G N D
P M E
W O L
