To use an external CNR card, the onboard audio CODEC can be enabled or disabled via this
jumper. Please disable the onboard audio CODEC if you want to use a PCI Sound Card or an
CNR Audio Card. When you install a CNR card, remember that the onboard audio CODEC
uses the primary channel. Therefore, if you want the onboard CODEC to work, you must set the
CNR to be secondary.
HARDWARE INSTALLATION
9
Audio Selection Jumper
J P 2
A u d i o
E n a b l e
Disable
Transcend
1
2
3
1
2
3
1
2
3
2.3.3 Onboard Audio Setting (JP2 ON-BOARD AUDIO)
