52 PCM-5896 User Manual
- LBA (Logical Block Addressing): During drive accesses, the
IDE controller transforms the data address described by
sector, head, and cylinder number into a physical block
address, significantly improving data transfer rates. For
drives with greater than 1024 cylinders.
Drive A
Drive B
Select the correct specifications for the diskette drive(s) installed in
the computer.
None No diskette drive installed
360K, 5.25 in 5-1/4 inch PC-type standard drive; 360
kilobyte capacity
1.2M, 5.25 in 5-1/4 inch AT-type high-density drive; 1.2
megabyte capacity
720K, 3.5 in 3-1/2 inch double-sided drive; 720 kilobyte
capacity
1.44M, 3.5 in 3-1/2 inch double-sided drive; 1.44 mega
byte capacity
2.88M, 3.5 in 3-1/2 inch double-sided drive; 2.88 mega
byte capacity
LCD & CRT
This field may appear as an alternative to the Video field. select
your video display device:
LCD Liquid crystal display
CRT Auxiliary monitor
AUTO The BIOS autosenses the device in use
(This value lets you switch between devices
without being left "in the dark").
LCD & CRT Display on both devices
