Usb connector (cn3) – IBM All-in-One Super7 Single Board Computer PCM-5896 User Manual
Page 38
26 PCM-5896 User Manual
USB connector (CN3)
The PCM-5896 provides two USB (Universal Serial Bus) interfaces,
which give complete plug and play, hot attach/detach for up to 127
external devices. The USB interfaces comply with USB specifica-
tion Rev. 1.0, and can be disabled in the system BIOS setup.
USB connector (CN3)
Pin
Function
Pin
Function
1
Vcc
5
Vcc
2
UD1-
6
UD0-
3
UD1+
7
UD0+
4
GND
8
GND
