Chapter 2 Installation 17

Clear CMOS (J2)

You can use J2 to clear the CMOS data if necessary. To reset the
CMOS data, place a jumper on J2 for just a few seconds, and then
remove the jumper.

Clear CMOS (J2)

Protect*

Clear CMOS

J2

*default

1

2

1

2
