Ethernet LED signal connectors
(LED1)
The PCM-5896 supports three sets of LED connector for external
LED indicators.
Ethernet active signal LED
Flashing Tx or Rx LEDs indicate that the PCM-5896 is transmitting
or receiving data.
Ethernet link signal LED
A continuously lit LED indicates good linkage between the
PCM-5896 and its supporting hub.
Ethernet LED signal connectors (LED1)
Pin
Signal
1
Rx LED
2
+5V
3
Link LED
4
+5V
5
Tx LED
6
+5V
