Chapter 2 Installation 31
Display connectors (CN9, CN12)
The mainboard's PCI SVGA interface can drive conventional CRT
displays and is capable of driving a wide range of flat panel
displays, including electroluminescent (EL), gas plasma, passive
LCD, and active LCD displays. The board has two connectors to
support these displays, one for standard CRT VGA monitors and
one for flat panel displays.
VGA display connector (CN12)
CN12 is a 16-pin, dual-in-line header used for conventional CRT
displays. A simple one-to-one adapter can be used to match CN12
to a standard 15-pin D-SUB connector commonly used for VGA.
VGA display connector (CN12)
Pin Signal Pin Signal
1 RED 9 SIGNAL GND
2 N/C 10 H-SYNC
3 GREEN 11 CHASSIS GND
4 SIGNAL GND 12 V-SYNC
5 BLUE 13 CHASSIS GND
6 N/C 14 N/C
7 N/C 15 CHASSIS GND
8 N/C 16 N/C
