32 PCM-5896 User Manual
LCD connector (CN9)
CN9 is a 50-pin, dual-in-line header used for flat panel displays.
When the mainboard's power is applied, the control signal is low
until just after the relevant flat panel signals are present.
Configuration of the VGA interface is done completely via the
software utility. You do not have to set any jumpers.
LCD connector (CN9)
Pin Signal Pin Signal
1 +12 V
DC
2 +12 V
DC
3 GND 4 GND
5 +5 V
DC
6 +5 V
DC
7 ENAVEE 8 GND
9 P0 10 P1
11 P2 12 P3
13 P4 14 P5
15 P6 16 P7
17 P8 18 P9
19 P10 20 P11
21 P12 22 P13
23 P14 24 P15
25 P16 26 P17
27 P18 28 P19
29 P20 30 P21
31 P22 32 P23
33 P24 34 P25
35 SHF CLK 36 FLM (V SYS)
37 M 38 LP (H SYS)
39 GND 40 ENABKL
41 P26 42 P27
43 P28 44 P29
45 P30 46 P31
47 P32 48 P33
49 P34 50 P35
