GA-4MXSV Motherboard
A.
CPU
U.
PCI_B
B.
Intel
Mukilteo
V
PCI_A
C.
Intel 6702 PXH-V
W.
PCI-E x8
D.
Intel ICH7R
X.
PCI-X_2
E.
ITE IT8712F
Y.
PCI-X_1
F.
SATA1
Z.
BAT (Battery)
G.
SATA2
1.
ATX
H.
SATA3
2.
ATX12V
I.
SATA4
3.
WOR
J.
FDC
4.
WOL
K.
IDE
5.
UF1 (CPU FAN)
L.
F_Panel
6.
UF2 (System FAN)
M.
COM2
7.
UF3 (System FAN)
N.
USB2
8.
UF4 (System FAN)
O.
Intel 82573V GbE
9.
UF5 (System FAN)
P.
ATI RN50
Q.
DDRII A1
R.
DDRII A2
S.
DDRII B1
T.
DDRII B2
