GA-4MXSV Motherboard
Parallel Port
This allows users to configure parallel port by using this option.
Enabled Enable the configuration.
Disabled Disable the configuration. (Default value)
Mode
This option allows user to set Parallel Port transfer mode.
Bi-directional Use this setting to support bi-directional transfers on the parallel
port. (Default value)
EPP Using Parallel port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port.
Base I/O Address
378 Set IO address to 378
278 Set IO address to 278.
IRQ
IRQ5 Set Interrupt as IRQ5. (Default value)
IRQ7 Set Interrupt as IRQ7 . (Default value)
PS/2 Mouse
Set this option ‘Enabled’ to allow BIOS support for a PS/2 - type mouse.
Enabled ‘Enabled’ forces the PS/2 mouse port to be enabled regardless if a
mouse is present. (Default value)
Disabled ‘Disabled’ prevents any installed PS/2 mouse from functioning, but
frees up IRQ12.
USB Controller
This item allows users to enable or disable the USB device by setting item to the desired value.
Enabled Enable USB controller. (Default value)
Options Disbale this function.
