Integra DTR-4.5 - Manual (Page 83)

83
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■
Audio Inputs
■ Audio Outputs
■ Other Jacks
Specifications and features are subject to change without
notice.
Power Output
(2 channels driven):
85 W + 85 W (8 Ω ,20Hz–20kHz, FTC)
Dynamic Power 220 W + 220 W (3 Ω ,Front)
165 W + 165 W (4 Ω ,Front)
100 W + 100 W (8 Ω ,Front)
THD (Total Harmonic
Distortion) 0.08 % (Power Rated)
Damping Factor 60 (Front,1kHz,8 Ω )
Input Sensitivity and
Impedance 200 mV/ 47 k Ω (LINE)
Output Level and
Impeadance 200 mV/ 470
Ω
(REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB-3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 10 kHz (TREBLE)
SN Ratio 106 dB (LINEIHF-A)
Speaker Impedance 6 Ω – 8 Ω
Input Sensitivity/Output
Level and Impedance
1 Vp-p /75 Ω (Component and S-Video Y)
0.7 Vp-p /75 Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 Ω (S-Video C)
1 Vp-p /75 Ω (Composite)
Component Video
Frequency Response
5 Hz – 50 MHz
Tuning Frequency Range 87.5 MHz– 107.9 MHz
Usable Sensitivity Stereo:17.2 dBf 2 µV(75 Ω IHF)
Mono: 11.2 dBf 1 µV(75 Ω IHF)
S/N Ratio Stereo: 70 dB (IHF-A)
Mono:76 dB (IHF-A)
THD Stereo: 0.3 % (1kHz)
Mono:0.2 % (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 45 dB ( 1kHz )
Tuning Frequency Range 530 kHz–1700 kHz
Usable Sensitivity 30 µV
S/N Ratio 40 dB
THD 0.70%
Power Supply AC 120 V, 60 Hz
Power Comsumption 5.7A
Stand-by Power
Comsumption
1.0 W
Dimensions(W x H x D) 17-1/8" W x 6-7/8" H x 16-7/8" D inches
Weight
27.6 lbs
Component Video Input 1,2,3
S-Video Compatible Jack
Input DVD,VIDEO1,VIDEO2,VIDEO3
A/V Input
DVD,VIDEO1,VIDEO2,VIDEO3
Component Video
Output
OUT
S-Video Compatible Jack
Output
MONITOR OUT,VIDEO1,VIDEO2
A/V Output MONITOR OUT,VIDEO1,VIDEO2
Digital Inputs Optical : 2
Coaxial : 2
Analog Inputs DVD(MULTICHANNEL),VIDEO1,
VIDEO2,VIDEO3,TAPE,CD
Multichannel Inputs 6
Digital Outputs 1 (Optical)
Analog Outputs TAPE,VIDEO1,VIDEO2
Subwoofer Pre Outputs 1
Speaker Outputs
7
Phones 1
RS-232 Control 1
IR Input/Output 1
12V Trigger Out 3
