First Time Setup —Continued
Speaker Distance
Here you can specify the distance from each speaker to
the listening position so that the sound from each speaker
arrives at the listener’s ears as the sound designer
intended.
Notes:
• The Center and Subwoofer distances can be set up to
5 ft. (1.5 m) more or less than the Front distance. For
example, if the Front distance is set to 20 ft. (6 m), the
Center and Subwoofer distances can be set between 15
and 25 ft. (4.5 and 7.5 m). The SurrRight, Surr Left,
and Surr Back distances can be set up to 5 ft. (1.5 m)
more or 15 ft. (4.5 m) less than the Front distance. For
example, if the Front distance is set to 20 ft. (6 m), the
SurrRight, Surr Left, and Surr Back distances can be
set between 5 and 25 ft. (1.5 and 7.5 m).
• This procedure can also be performed on the AV
receiver by using its [Setup] button, arrow buttons, and
[Enter] button.
1 Press the [Receiver] button fol-
lowed by the [Setup] button.
The main menu appears onscreen.
2 Use the Up and Down [ ]/[ ]
buttons to select “2. Speaker
Setup,” and then press [Enter].
The Speaker Setup menu appears.
3 Use the Up and Down [ ]/[ ]
buttons to select “2. Speaker Dis-
tance,” and then press [Enter].
Display Muting
Random Rec
Exit
Gu id e
Prev
CH
--/---
Dimmer
Tape
TV
Input
Sleep
Enter
To p M enu Men u
Set up Retu
rn
VOL CH
Disc
SAT T V VCR Cable
DVD Receiver C D
+10 0 Clear
Macro
1 2 3
MD/CDR
+
-
Input Selector
Remote Mode
Zone 2
1, 7
2–5
2, 3
1
Receiver
Enter
Enter
Enter
Enter
The Speaker Distance menu appears.
Note:
Speakers that you set to No or None on
the Speaker Configuration page
(page 39) cannot be selected.
4 Use the Up and Down [ ]/[ ]
buttons to select “a. Unit,” and
then use the Left and Right [
]/
[ ] buttons to select:
feet: Select if you want to enter
distances in feet. Can be set
from 1 to 30 feet in 1-foot
steps.
meters: Select if you want to enter
distances in meters. Can be
set from 0.3 to 9 meters in
0.3-meter steps.
5 Use the Up and Down [ ]/[ ]
buttons to select “b. Left,” and
then use the Left and Right [
]/
[ ] buttons to specify the dis-
tance.
Specify the distance from the front left
speaker to your listening position.
6 Repeat step 5 for all speakers.
7 Press the [Setup] button.
The setup menu closes.
Menu
------------------------
1.Initial Setup
2.Speaker Setup
Advanced Setup
3.Surround Setup
4.Audio Adjust
5.Listening Mode Preset
6.Preference
Basic Setup
2.Speaker Setup
------------------------
2.Speaker Distance
3.Level Calibration
4.Equalizer Settings
1.Speaker Config
2-2.Speaker Distance
------------------------
b.Front : 12ft
c.Center : 12ft
d.Surr Right : 7ft
e.Surr Left : 7ft
f.Subwoofer : 12ft
a.Unit :feet
Enter
Enter
