RAID Configuration

Page 5-3

Intel ICH6R RAID features

•

Support RAID 0, 1

•

RAID 1 spare and auto-rebuild support

•

RAID 1 mirror restore without user interaction

•

Support for 2 RAID arrays on 4 ports

•

Support “RAID Ready” – pre-install RAID on one single drive and upgrade
to RAID arrays in the future when more drives are added.

•

Intel Application Accelerator - Powerful software for RAID control and
management under Windows environment

•

Support “Hot-plug” – disconnect and rebuild RAID on-the-fly

•

Support Intel Matrix RAID technology – Segments the HDD into separate
RAID volumes. (See diagram below)

• For more information on creating RAID arrays or migrating to RAID with

ICH6R, refer to user guide in the bundled CD.

For optimum system performance on 2 SATA drives we recommend to
use Intel’s Matrix RAID configuration. See Appendix C in this manual
for a Quick Guide to set up Intel Matrix RAID.
