Intel KM4AM User Manual
Page 73
MS-6734 M-ATX Mainboard
4 - 1 4
Click on the plus (+) symbol next to Array 0---RAID 0 to see the details of each disk.
Click on
o r
button to determine the viewing type of left window pane.
There are two viewing types: By controllers and by device. Click on the object in the
left window pane to display the status of the object in the right windowpane. The
following screen shows the status of Array 0---RAID 0.
