Intel KM4AM - Manual (Page 63)

MS-6734 M-ATX Mainboard
4 - 4
Create Disk Array
Use the up and down arrow keys to select the Create Array command and press
.
Select Array Mode and press , a list of array modes will appear. Highlight
the target array mode that you want to create, and press to confirm the
selection. If RAID 1 or RAID 0/1 is selected, an option list will popup and enable the
users to select Create only or Create and duplicate. Create only will allow BIOS
to only create an array. The data on the mirroring drive may be different from the
source drive. Create and duplicate lets BIOS copy the data from the source to the
mirroring drive.
MSI Reminds You...
The “Channel”, “Drive Name”, “Mode” and “Size (GB)” in the following
example might be different from your system.
