25 Chapter 3
3.2 Connections to Three Standard LCDs
The following tables illustrate typical LCD connection pinouts for the
PCM-9586.
3.2.1 LG LM150X06 (1024x768(16 colors) LVDS LCD)
* LCD connector type: HRS DF 19K-20P-1H or compatible
Table 3.1: Connections to LCD/ Flat Panel (CN16)
LCD Connector Flat Panel Connector
Unipac-UB104S01
DF-13 40P
Pin Signal Pin Signal
1 Vcc 1 3.3V
2 Vcc 2 3.3V
3 GND 3 GND
4 GND 4 GND
5 RxIN0- 7 LVDS_YAM0R
6 RxIN0+ 9 LVDS_YAP0R
7 GND 11 GND
8 RxIN1- 13 LVDS_YAM1R
9 RxIN1+ 15 LVDS_YAP1R
10 GND 17 GND
11 RxIN2- 19 LVDS_YAM2R
12 RxIN2+ 21 LVDS_YAP2R
13 GND 23 GND
14 CKIN- 25 LVDS-CLKAMR
15 CKIN+ 27 LVDS-CLKAPR
16 GND 29 GND
17 NC
18 NC
19 GND 33 GND
20 GND 34 GND
