1 - 1
SECTION 1 SPECIFICATIONS
[USA] [EXP] [EUR]
GENERAL
• Frequency coverage 136–174 MHz
• Type of emission Wide 16K0F3E (25.0 kHz)
Middle – 14K0F3E (20.0 kHz)
Narrow
11K0F3E (12.5 kHz)
8K10F1E/D (12.5 kHz)
4K00F1E/D(6.25 kHz)
8K50F3E (12.5 kHz)
4K00F1E/D (6.25 kHz)
• Number of programable channels max. 512 channels (128 zones)
• Antenna impedance 50 Ω (nominal)
• Operating temperature range −30˚ to +60˚; −22˚F to +140˚F –25˚C to +55˚C
• Power supply requirement
(negative ground)
13.6 V DC (nominal) 13.2 V DC (nominal)
• Current drain
(approx.)
RX
Stand-by 300 mA
Max.audio 1200 mA
TX
at 25 W 7 A
at 50 W 14 A
• Dimensions (projections not included)
160 (W) × 45 (H) × 150 (D) mm; 2 3 / 32 (W) × 4 23 / 32 (H) × 1 9 / 32 (D) in
• Weight (with BP-231, approx.) 1310 g; 2 Ib 14 oz
TRANSMITTER
• Transmit output power 50 W 25 W
• Modulation Variable reactance frequency modulation
• Max. permissible deviation Wide ±5.0 kHz
Middle – ±4.0 kHz
Narrow ±2.5 kHz
• Frequency error ±1.0 ppm ±1.5 kHz
• Spurious emission
75 dB typ.
0.25 µW (≤1 GHz),
1.0 µW (>1 GHz)
• Adjacent channel power Wide More than 70 dB
Middle – More than 70 dB
Narrow More than 60 dB
• Audio harmonic distortion 3% typ. (with 1 kHz AF 40% deviation)
• FM hum and noise
(without CCITT filter) Wide More than 40 dB (45 dB typ.) –
Narrow More than 34 dB (40 dB typ.) –
• Limiting charact of modulation 70–100% of max. deviation
• Microphone impedance 600 Ω
RECEIVER
• Receive system Double-conversion superheterodyne
• Intermediate frequencies 1st IF; 46.35 MHz, 2nd IF; 450 kHz
• Sensitivity
0.25 µV typ. at 12 dB SINAD
−4 dB µV (EMF) typ.
at 20 dB SINAD
• Squelch sensitivity (at threshold) 0.25 µV typ.
• Adjacent channel
selectivity Wide More than 80 dB (85 dB typ.)
Middle − More than 78 dB (83 dB typ.)
Narrow More than 70 dB (75 dB typ.)
• Spurious response More than 85 dB (90 dB typ.)
• Intermodulation More than 75 dB (77 dB typ.) More than 65 dB (70 dB typ.)
• Hum and noise
(without CCITT filter) Wide More than 45 dB (50 dB typ.) –
Narrow More than 40 dB (45 dB typ.) –
• Audio output power 4 W typ. at 10% distortion with a 4 Ω load
• Audio output impedance 4 Ω
All stated specifications are subject to change without notice or obligation.
Measurements made in accordance with EIA-152-C/204D, TIA-603 ([USA], [EXP] ) or EN 300 086 ([EUR]).
