6 - 1
SECTION 6 ADJUSTMENT PROCEDURES
6-1 PREPARATION
When adjusting IC-F5060 series transceiver, CS-F5060 CLONING SOFTWARE, CS-F5060 ADJ ADJUSTMENT SOFTWARE (Rev. 1.0 or lat-
er), RS-232C cable , JIG cable (modifi ed OPC-1122/U CLONING CABLE ; see the page 6-2) and the following test equipments are required.
EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE
DC power supply
Output voltage
Current capacity
: 13.6 V DC [USA]
13.2 V DC [EUR], [EXP]
: More than 1.5 A
Attenuator
Power attenuation
Capacity : 50 or 60 dB
: 60 W [USA]
30 W [EUR], [EXP]
modulation analyzer
Frequency range
Measuring range : DC–300 MHz
: 0 to
±10 kHz
External speaker
Input impedance
Capacity : 4 Ω
: 5 W or more
Frequency counter
Frequency range
Frequency accuracy
Sensitivity : 0.1–300 MHz
: ±1 ppm or better
: 100 mV or better
Standard signal
generator (SSG) Frequency range
Output level
: 0.1–300 MHz
: 0.1 µV to 32 mV
(–127 to –17 dBm)
RF power meter
Measuring range
Frequency range
Impedance
SWR
: 0.1–60 W [USA]
0.1–30 W [EUR], [EXP]
: 100–300 MHz
: 50
Ω
: Better than 1.2 : 1
Oscilloscope
Frequency rang
Measuring range : DC–20 MHz
: 0.01–20 V
Digital voltmeter
Input impedance
Measuring range : 50 k Ω
: 0.1–10V
▄ SYSTEM REQUIREMENTS
(for the ADJUSTMENT SOFTWARE)
• Microsoft
®
Windows
®
98/98SE/Me/2000/XP • RS-232C serial port (D-sub 9 pin)
▄ STARTING SOFTWARE ADJUSTMENT
q Connect the transceiver and PC with RS-232C cable and
JIG CABLE .
w Turn the transceiver power ON.
e Boot up Windows, and click the program group ‘CS-F5060
ADJ’ in the ‘Programs’ folder of the [Start] menu, then
CS-F5060 ADJ’s window appears.
r Click ‘Connect’ on the CS-F5060 ADJ’s window, then the
window shows transceiver’s condition and adjustment
items as below.
t Set or modify adjustment data as specifi ed.
▄ BEFORE STARTING SOFTWARE ADJUSTMENT
Clone the adjustment frequencies and settings into the transceiver, and set the confi guration using the CS-F5060 CLONING SOFT-
WARE before starting the software adjustment. Otherwise, the software adjustment can not be started.
CAUTION!: BACK UP the originally programmed memory data in the transceiver before programming the adjustment frequencies.
When program the adjustment frequencies into the transceiver, the transceiver’s memory data will be overwritten and
lose original memory data at the same time.
Microsoft and Windows are registered trademarks of Micro-
soft Corporation in the U.S.A. and other countries.
▄ ADJUSTMENT SOFTWARE INSTALLATION
q Quit all applications when Windows is running.
w Insert the CD into the appropriate CD drive.
e Double-click the “Setup.exe” contained in the ‘CS-F5060
ADJ’ folder in the CD drive.
r The “Welcome to the InstallShield Wizard for CS-F5060
ADJ” will appear. Click [Next>].
t The “Choose Destination Location” will appear. Then click
[Next>] to install the software to the destination folder. (e.g.
C:\Program Files\Icom\CS-F5060 ADJ)
y After the installation is completed, the “InstallShield Wiz-
ard Complete” will appear. Then click [Finish].
u Eject the CD.
i Program group ‘CS-F5060 ADJ’ appears in the ‘Programs’
folder of the start menu, and ‘CS-F5060 ADJ’ icon ap-
pears on the desk top screen.
• ADJUSTMENT FREQUENCY LIST
CH FREQUENCY SETTING CH FREQUENCY SETTING
1 154.900 MHz
• TX power
• Mode : Low1
: Narrow
10 174.000 MHz
• TX power
• Mode : Low1
: Narrow
2 174.000 MHz
• TX power
• Mode : Low1
: Wide
11* 155.000 MHz
• TX power
• Mode : Low1
: Middle
3 136.000 MHz
• TX power
• Mode : Low1
: Wide
12* 136.000 MHz
• TX power
• Mode : High
: Middle
4 155.000 MHz
• TX power
• Mode : Low1
: Wide
13* 174.000 MHz
• TX power
• Mode : Low2
: Middle
5 136.000 MHz
• TX power
• Mode : High
: Narrow
14 155.000 MHz
• TX power
• Mode : Low1
: Digital
6 136.000 MHz
• TX power
• Mode : Low2
: Wide
15 136.000 MHz
• TX power
• Mode : Low1
: Digital
7 155.000 MHz
• TX power
• Mode
• DTCS : Low1
: Middle
: 007
16 174.000 MHz
• TX power
• Mode : Low1
: Digital
8 155.000 MHz
• TX power
• Mode : Low1
: Narrow
17 136.000 MHz
• TX power
• CTCSS : Low1
: 151.4 Hz
9 136.000 MHz
• TX power
• Mode : Low1
: Narrow
18 136.000 MHz
• TX power
• Mode
• DTMF : Low1
: Wide
: P3
*; [EUR] only
