This service manual describes the latest service information
for the IC-F5061/F5062/F5063 VHF TRANSCEIVERS at the
time of publication.

NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 15 V. This will ruin the
transceiver.

DO NOT expose the transceiver to rain, snow or any liquids.

DO NOT reverse the polarities of the power supply when
connecting the transceiver.

DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the transceiver’
s front end.

To upgrade quality, any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.

MODEL

VERSION CHANNEL SPACING TX POWER

IC-F5061

USA-01

15.0/30.0 kHz

50 W

IC-F5062

EXP-01

12.5/25.0 kHz

25 W

IC-F5063

EUR-01

12.5/20/25.0 kHz

Be sure to include the following four points when ordering
replacement parts:

1. 10-digit Icom parts numbers
2. Component part number and name
3. Equipment model name and unit name
4. Quantity required

1110003491 S.IC TA31136FNG IC-F5061

MAIN UNIT 5 pieces

8820001210 Screw 2438 screw

IC-F5062

Top cover

10 pieces

Addresses are provided on the inside back cover for your
convenience.

Icom, Icom Inc. and

logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United

Kingdom, Germany, France, Spain, Russia and/or other countries.

ORDERING PARTS

1. Make sure a problem is internal before disassembling

the transceiver.

2. DO NOT open the transceiver until the transceiver is

disconnected from its power source.

3. DO NOT force any of the variable components. Turn

them slowly and smoothly.

4. DO NOT short any circuits or electronic parts. An

insulated tuning tool MUST be used for all adjustments.

5. DO NOT keep power ON for a long time when the

transceiver is defective.

6. DO NOT transmit power into a signal generator or a

sweep generator.

7. ALWAYS connect a 50 dB to 60 dB attenuator between

the transceiver and a deviation meter or spectrum
analyzer when using such test equipment.

8. READ the instructions of test equipment thoroughly

before connecting equipment to the transceiver.

REPAIR NOTES

INTRODUCTION

CAUTION

This manual is related to the following products:
