Main unit – Icom IC-F5061 User Manual
Page 23
7 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
R221
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
44.4/49.8
R222
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
17.7/33.9
R223
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
16.2/33.9
R224
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
15.7/32.7
R225
7030005000 S.RES ERJ2GEJ 471 X (470)
B
8/19.2
R226
7030004980 S.RES ERJ2GEJ 101 X (100)
T
109.7/53.5
R227
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
107.1/49.3
R228 7410001140
S.ARY
EXB28V104JX
T 103.3/49
R230
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
124.7/42.7
R232
7030005530 S.RES ERJ2GEJ 100 X (10)
T
120.4/41.1
R233
7410000750 S.ARY EXB-V4V 104JV (100 k)
T
130/34.7
R234 7410001130
S.ARY
EXB28V102JX
B
129.4/34.4
R236
7030009530 S.RES ERJ2GEJ 270 X (27)
B
63.9/71.5
R237
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
B
65.3/69.7
R238
7030005060 S.RES ERJ2GEJ 333 X (33 k)
[EXP-01],
[EUR-01]
B
61.9/65.1
7030008010 S.RES ERJ2GEJ 123 X (12 k) [USA-01] B
61.9/65.1
R240
7030005570 S.RES ERJ2GEJ 820 X (82)
B
62.4/67.4
R241
7030004980 S.RES ERJ2GEJ 101 X (100)
B
58.5/66
R242
7030004970 S.RES ERJ2GEJ 470 X (47)
T
12/33.1
R243
7030009320 S.RES ERJ2GEJ 4R7 X (4.7)
T
10/36
R244
7030005000 S.RES ERJ2GEJ 471 X (470)
B
15.1/36.3
R245
7030005530 S.RES ERJ2GEJ 100 X (10)
B
11.9/39.9
R246
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
7.5/38.6
R247
7030004990 S.RES ERJ2GEJ 221 X (220)
B
7.7/36.3
R248 7410001130
S.ARY
EXB28V102JX
B
103.9/47.9
R249 7410001130
S.ARY
EXB28V102JX
B
123.9/27.6
R250 7410001130
S.ARY
EXB28V102JX
B
122.1/25.7
R251 7410001140
S.ARY
EXB28V104JX
T
124.7/28.7
R252 7410001140
S.ARY
EXB28V104JX
T
122.1/25.7
R253
7030005720 S.RES ERJ2GEJ 563 X (56 k)
T
9.5/40.5
R254
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
7.4/42.2
R255
7030005310 S.RES ERJ2GEJ 124 X (120 k)
B
6.6/38.6
R256
7030006610 S.RES ERJ2GEJ 394 X (390 k)
T
13/41
R257
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
T
9/42.2
R258
7030005170 S.RES ERJ2GEJ 474 X (470 k)
T
11/44.5
R259
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
6/45.1
R260
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
6/47
R261 7410001130
S.ARY
EXB28V102JX
B 99.7/43.5
R262 7410001130
S.ARY
EXB28V102JX
T
100.2/37.4
R263 7410001130
S.ARY
EXB28V102JX
B 97/40.7
R264 7410001140
S.ARY
EXB28V104JX
T 103.8/37
R265
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
103.8/39.2
R266 7410001130
S.ARY
EXB28V102JX
B
120.1/23.5
R267 7410001130
S.ARY
EXB28V102JX
B
118.3/21.7
R268 7410001130
S.ARY
EXB28V102JX
B
116.5/19.9
R269
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
119.4/20.8
R271
7030004980 S.RES ERJ2GEJ 101 X (100)
T
77.6/78.5
R272
7030007280 S.RES ERJ2GEJ 331 X (330)
T
61/76.5
R273
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
62.3/76.1
R274
7030004980 S.RES ERJ2GEJ 101 X (100)
T
56.7/69.3
R275
7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
T
64.8/73.8
R276
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
T
65.8/73.8
R277
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
4.8/45.6
R278
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
132.2/29.9
R279
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
131.3/29.9
R280 7410001130
S.ARY
EXB28V102JX
B 95.2/38.9
R281
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
93.7/48.8
R282
7410000750 S.ARY EXB-V4V 104JV (100 k)
T
97.2/45.3
R283 7410001130
S.ARY
EXB28V102JX
T
103.1/21.7
R284
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
111.2/25.1
R285 7410001130
S.ARY
EXB28V102JX
B
107.1/19.9
R286 7410001140
S.ARY
EXB28V104JX
T
121.7/22.2
R287
7030004990 S.RES ERJ2GEJ 221 X (220)
T
55.7/72.6
R288
7030005100 S.RES ERJ2GEJ 154 X (150 k)
T
54.1/68.2
7030005170 S.RES ERJ2GEJ 474 X (470 k) [USA-01] B
38/63.7
7030008300 S.RES ERJ2GEJ 184 X (180 k)
[EXP-01],
[EUR-01]
B
38/63.7
R290 7520000260
S.POS
PRF18BB471QB1RB
[USA-01]
only
T
33.9/63
R291
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
109.2/24.5
R292 7030006070
S.RES
ERJ12YJ101U
(100)
B 43.6/66.1
R293
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
50.6/70.5
R294
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
51.7/68.2
R295
7030008290 S.RES ERJ2GEJ 183 X (18 k)
T
50.6/71.4
R296
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
T
53.8/64.2
R297
7030008010 S.RES ERJ2GEJ 123 X (12 k)
T
50.5/68.6
R298
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
45.6/69.9
R300
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
99.9/59.6
R301
7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
T
106.2/55.6
R302 7030000480
S.RES
MCR10EZHJ
6.8
k
T 79/64.4
R303
7030000480 S.RES MCR10EZHJ 6.8 k
T
80.9/64.4
R304
7030000440 S.RES MCR10EZHJ 3.3 k
T
82.8/64.4
R305
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
40.3/19.4
R306
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
T
41/21.7
R307
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
27/63
R309
7030005070 S.RES ERJ2GEJ 683 X (68 k)
T
89.9/7.2
R310
7030004980 S.RES ERJ2GEJ 101 X (100)
B
109.3/62.8
R311
7030000220 S.RES MCR10EZHJ 47 (470)
B
15/76.9
R312
7030005700 S.RES ERJ2GEJ 274 X (270 k)
B
31.5/62.4
R313 7030003370
S.RES
ERJ3GEYJ
271
V
(270)
B 8.6/54
R314
7030005600 S.RES ERJ2GEJ 273 X (27 k)
B
3/53
R315
7030000220 S.RES MCR10EZHJ 47 (470)
B
3.5/57.4
R316
7030005170 S.RES ERJ2GEJ 474 X (470 k)
T
90.8/11.3
R317
7030005160 S.RES ERJ2GEJ 105 X (1 M)
B
108.3/83.7
R318
7030005160 S.RES ERJ2GEJ 105 X (1 M)
B
112.5/82.7
R319
7030005120 S.RES ERJ2GEJ 102 X (1 k)
B
112.1/81.5
R320
7030005160 S.RES ERJ2GEJ 105 X (1 M)
B
107.2/82.4
R321
7030004970 S.RES ERJ2GEJ 470 X (47)
B
108.4/82
R322
7030005600 S.RES ERJ2GEJ 273 X (27 k)
B
2.1/79.2
R323 7030003370
S.RES
ERJ3GEYJ
271
V
(270)
B 6.3/78.7
R324 7030000620
S.RES
MCR10EZHJ
100
k
B 5.6/85.5
R325
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
130.5/45.2
R326
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
131.8/51.7
S.=Surface mount
[MAIN UNIT]
REF
ORDER
DESCRIPTION
M.
H/V
NO.
NO.
LOCATION
R327
7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
B
131.1/54.2
R328
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
134.2/51.7
R331
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
110.1/21.6
R332
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
109.6/27.9
R333
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
109.6/26.9
R334
7030000100 S.RES MCR10EZHJ 4.7 (4R7)
T
101.4/79.7
R335
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
101.8/83.9
R336
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
111.3/78.5
R337 7410001130
S.ARY
EXB28V102JX
T
104.6/75.9
R338
7030005651 S.RES ERA3YKD 304V (300 k)
T
113.6/54.3
R339
7030005871 S.RES ERA3YKD 104V (100 k)
T
113.6/52.9
R340
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
T
136.3/65.7
R341
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
B
130.7/85.9
R342
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
135.4/52.2
R343
7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
B
138.2/49.4
R344
7030005110 S.RES ERJ2GEJ 224 X (220 k)
B
133.3/54.6
R345
7030005110 S.RES ERJ2GEJ 224 X (220 k)
B
133.3/56.3
R346
7030008410 S.RES ERJ2GEJ 392 X (3.9 k)
B
137/52.2
R347
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
137.8/53.7
R348
7030005700 S.RES ERJ2GEJ 274 X (270 k)
B
129.1/77.2
R349
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
127.8/77.7
R350
7030005120 S.RES ERJ2GEJ 102 X (1 k)
B
139.1/47.8
R351
7030004980 S.RES ERJ2GEJ 101 X (100)
B
136.3/38.1
R352
7030008300 S.RES ERJ2GEJ 184 X (180 k)
B
139.7/39
R353
7030005230 S.RES ERJ2GEJ 334 X (330 k)
B
138.2/47.8
R354 7030010040
S.RES
ERJ2GEJ-JPW
T 140.4/36
R355
7030008280 S.RES ERJ2GEJ 271 X (270)
B
139.7/34.3
R356 7540000290
ABS ERZV10D220
R359
7030005090 S.RES ERJ2GEJ 104 X (100 k)
B
114.8/82.9
R360
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
80.6/5.3
R361
7030005600 S.RES ERJ2GEJ 273 X (27 k)
T
78.4/5.3
R362
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
124.8/50.2
R363
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
42.9/38.3
R364
7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
T
42.9/37.4
R365
7030004970 S.RES ERJ2GEJ 470 X (47)
T
38.3/37.9
R366
7030005050 S.RES ERJ2GEJ 103 X (10 k)
B
131.4/63.4
R367
7030005000 S.RES ERJ2GEJ 471 X (470)
B
130.1/63
R368
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
78.3/7.6
R370
7030005010 S.RES ERJ2GEJ 681 X (680)
T
71.2/70.4
R371
7030005050 S.RES ERJ2GEJ 103 X (10 k)
T
119.5/84.6
R372
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
T
25.9/8.1
R373
7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
T
74/21.6
R375
7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
T
27.6/5.3
R376
7030005160 S.RES ERJ2GEJ 105 X (1 M)
B
109.1/12.1
R377
7030005160 S.RES ERJ2GEJ 105 X (1 M)
B
110.9/12.1
R378 7410001140
S.ARY
EXB28V104JX
B
100.7/18.3
R379
7030005090 S.RES ERJ2GEJ 104 X (100 k)
T
111.6/23.8
R386
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
105.8/85.1
R387
7030005120 S.RES ERJ2GEJ 102 X (1 k)
T
107.8/85.1
C1 4030017420
S.CER
ECJ0EC1H470J
T
88.9/54.3
C2 4030017420
S.CER
ECJ0EC1H470J
T
89.9/54.3
C3 4030017420
S.CER
ECJ0EC1H470J
T
41.5/15.4
C4 4030017420
S.CER
ECJ0EC1H470J
B
50/15
C5 4030017460
S.CER
ECJ0EB1E102K
T
89.4/34
C6
4550007080 S.TAN TEESVA 1C 106M8R
T
80.8/55.1
C7 4030017420
S.CER
ECJ0EC1H470J
T
84/18.4
C8 4030017420
S.CER
ECJ0EC1H470J
T
89.9/52
C9 4030016930
S.CER
ECJ0EB1A104K
T
88.9/52
C10 4030016930
S.CER
ECJ0EB1A104K
T
80.6/50.7
C11 4030016930
S.CER
ECJ0EB1A104K
T
10.9/18.8
C12 4030016930
S.CER
ECJ0EB1A104K
T 8.5/7.4
C13 4030016930
S.CER
ECJ0EB1A104K
T 85.6/10
C14 4030016930
S.CER
ECJ0EB1A104K
T 86.6/10
C15 4030017460
S.CER
ECJ0EB1E102K
T
41.5/7.7
C16
4550000460 S.TAN TEESVA 1C 105M8R
T
42.7/6.2
C17
4550000460 S.TAN TEESVA 1C 105M8R
B
42.7/6.2
C18 4030017420
S.CER
ECJ0EC1H470J
T
41.5/14.5
C19 4030017420
S.CER
ECJ0EC1H470J
B
50/15.9
C20 4030016970
S.CER
ECJ0EB1C223K
B
100.9/52.3
C21 4030017420
S.CER
ECJ0EC1H470J
T
41.5/13.5
C22 4030017420
S.CER
ECJ0EC1H470J
T
41.5/12.6
C23 4030016930
S.CER
ECJ0EB1A104K
T
51.8/5.6
C24 4030017420
S.CER
ECJ0EC1H470J
B
39.8/9.8
C25 4030017420
S.CER
ECJ0EC1H470J
T 61.4/6
C26 4030016930
S.CER
ECJ0EB1A104K
B
37.2/5.8
C27 4030017760
S.CER
ECJ0EB1H222K
B
36.3/7.5
C28 4030016930
S.CER
ECJ0EB1A104K
T
79.3/7.6
C29 4030017460
S.CER
ECJ0EB1E102K
T 79/13.6
C30 4030016930
S.CER
ECJ0EB1A104K
T
78.1/13.6
C31 4030017460
S.CER
ECJ0EB1E102K
T
80.6/51.7
C32 4030017500
S.CER
ECJ0EC1H560J
B
33.3/15.9
C33 4030016930
S.CER
ECJ0EB1A104K
B
34.8/12.8
C34 4030017570
S.CER
ECJ0EC1H040B
B
32.1/15.4
C35 4030017590
S.CER
ECJ0EC1H070C
B
30.9/15.9
C36 4030016930
S.CER
ECJ0EB1A104K
T
22.4/14.9
C37 4030017360
S.CER
ECJ0EC1H030B
B
28.3/15.4
C38 4030016930
S.CER
ECJ0EB1A104K
T 22/6.2
C39 4030016930
S.CER
ECJ0EB1A104K
B
13.6/6.2
C40 4030016930
S.CER
ECJ0EB1A104K
T
23.8/6.2
C41 4030016930
S.CER
ECJ0EB1A104K
T 22/12.5
C42 4030016930
S.CER
ECJ0EB1A104K
T 23/12.5
C43 4030017430
S.CER
ECJ0EC1H101J
T
26.4/9.4
C44 4030017430
S.CER
ECJ0EC1H101J
T
25.5/9.4
C45 4030017790
S.CER
ECJ0EB1E682K
B
91.7/10
C46 4030016930
S.CER
ECJ0EB1A104K
B
93.8/10
C47 4030016970
S.CER
ECJ0EB1C223K
T
92.1/15.1
C48 4030017710
S.CER
ECJ0EC1H181J
B
49.7/9.1
C49
4550007080 S.TAN TEESVA 1C 106M8R
T
52.1/15.4
C50 4030017460
S.CER
ECJ0EB1E102K
T 54.3/12
C51 4030017400
S.CER
ECJ0EC1H220J
T 47.8/19
C52 4030017400
S.CER
ECJ0EC1H220J
T
44.7/7.8
C53 4030017900
S.CER
ECJ0EB1C123K
T
59.1/10.6
