82540EP — Networking Silicon
38 Datasheet
PCI_AD[9] N3
PCI_AD[7] N4
PCI_AD[4] N5
VDDO (3.3V) N6
PCI_AD[0] N7
VDDO (3.3V) N8
FL_SCK N9
EE_DO N10
NC N11
GND N12
SDP6 N13
SDP0 N14
NC P1
VDDO (3.3V) P2
PCI_AD[8] P3
PCI_AD[6] P4
PCI_AD[3] P5
PCI_AD[2] P6
EE_CS P7
GND P8
FL_SO P9
EE_DI P10
CTRL_15 P11
VDDO (3.3V) P12
SDP1 P13
NC P14
Table 36. Signal Names in Pin Order (Sheet 6 of 6) (Continued)
Signal Name Pin
