Intel 82540EP - Manual (Page 37)

Networking Silicon — 82540EP
Datasheet 31
Table 24. Power Management Signals
Signal Pin Signal Pin
LAN_PWR_
GOOD
A9 AUX_PWR J12
PME# A6 CLKRUN# C8
Table 25. Impedance Compensation Signals
Signal Pin Signal Pin
ZN_COMP H4 ZP_COMP G4
Table 26. SMB Signals
Signal Pin Signal Pin Signal Pin
SMBCLK A10 SMBDATA C9 SMBALRT# B10
Table 27. EEPROM and Serial FLASH Interface Signals
Signal Pin Signal Pin Signal Pin
EE_SK M10 EE_DI P10 FL_SCK N9
EE_DO N10 FL_CE# M9 FLSO P9
EE_CS P7 FL_SI M11
Table 28. LED Signals
Signal Pin Signal Pin
LED0 / LINK# A12 LED2 / LINK100# B11
LED1 / ACT# C11 LED3 / LINK1000# B12
Table 29. Other Signals
Signal Pin Signal Pin Signal Pin
SDP0 N14 SDP6 N13 CTRL_15 P11
SDP1 P13 SDP7 M12 CTRL_25 B13
Table 30. IEEE Test Signals
Signal Pin
CLK_VIEW M8
