82540EP — Networking Silicon
36 Datasheet
GND G11
AVDDL (2.5 V) G12
DVDD (1.5V) G13
GND G14
STOP# H1
INTA# H2
DEVSEL# H3
ZN_COMP H4
DVDD (1.5V) H5
DVDD (1.5V) H6
DVDD (1.5V) H7
DVDD (1.5V) H8
GND H9
GND H10
DVDD (1.5V) H11
NC H12
MDI3+ H13
MDI3- H14
PAR J1
PERR# J2
GNT# J3
NC J4
DVDD (1.5V) J5
DVDD (1.5V) J6
DVDD (1.5V) J7
DVDD (1.5V) J8
DVDD (1.5V) J9
DVDD (1.5V) J10
DVDD (1.5V) J11
AUX_PWR J12
NC J13
XTAL2 J14
PCI_AD[16] K1
GND K2
VDDO (3.3V) K3
VDDO (3.3V) K4
DVDD (1.5V) K5
DVDD (1.5V) K6
Table 36. Signal Names in Pin Order (Sheet 4 of 6) (Continued)
Signal Name Pin
