Installation Instructions
Section 2
2-22
Part Number 000000966
NON-MANITOWOC MULTI-CIRCUIT CONDENSER SIZING CHART
Typical Single Circuit Remote Condenser Installation
Ice
Machine
Model
Refrigerant
Heat of Rejection
Internal
Condenser
Volume (cu ft)
Design
Pressure
Quick Connect Stubs-
Male Ends
Head
Pressure
Control
Valve
Type
Charge
Average
Btu/hr
Peak
Btu/hr
Min
Max
Discharge
Liquid
S500
R-404A
6 lbs.
6,100
6,900
0.020
0.035
500 psig
(3447 kpa)
(34.47 bar)
safe working
pressure
coupling
P/N
83-6035-3
coupling
P/N
83-6034-3
Manitowoc
P/N
83-6809-3
S600
R404A
6.5 lbs.
9,000
13,900
0.045
0.060
S850
R-404A
8.5 lbs.
13,000
16,000
0.045
0.060
2,500 psig
(17237 kpa)
(172.37 bar)
burst
pressure
S1000
R-404A
8.5 lbs.
17,700
21,000
0.045
0.060
no
substitutes
S1400
R-404A
11 lbs.
20,700
24,500
0.085
0.105
mounting
flange P/N
83-6006-3
mounting
flange P/N
83-6005-3
S1600
R-404A
11.5 lbs
21,000
31,000
0.085
0.105
S1800
R-404A
12.5 lbs.
31,000
36,000
0.085
0.105
SV1615
SINGLE CIRCUIT REMOTE
CONDENSER
ELECTRICAL
DISCONNECT
DISCHARGE
LINE
LIQUID LINE
ELECTRICAL
DISCONNECT
ELECTRICAL
SUPPLY
ICE MACHINE
BIN
DISCHARGE
REFRIGERANT
LINE
LIQUID
REFRIGERANT
LINE
36.00"
(91.44 cm)
DROP
TO CIRCUIT
BREAKER
PANEL
