Remote Condenser/Line Set Installation

REMOTE ICE MACHINES
REFRIGERANT CHARGE

Each remote ice machine ships from the factory with a
refrigerant charge appropriate for installation with line
sets of up to 50' (15.25 m). The serial tag on the ice
machine indicates the refrigerant charge.

Additional refrigerant may be required for installations
using line sets between 50' and 100’ (15.25-30.5 m)
long. If additional refrigerant is required, refer to the
chart below for the correct amount to be added.

Typical Additional Refrigerant Label

Ice Machine

Remote Single

Circuit

Condenser

Line Set*

S500

JC0495

RT-20-R404A

RT-35-R404A

RT-50-R404A

S600/S800/S1000

JC0895

RT-20-R404A

RT-35-R404A

RT-50-R404A

S1400/S1600/

S1800

JC1395

RL-20-R404A

RL-35-R404A

RL-50-R404A

*Line Set

Discharge Line

Liquid Line

RT

1/2" (1.27 cm)

5/16" (.79 cm)

RL

1/2" (1.27 cm)

3/8" (.95 cm)

Air Temperature Around the Condenser

Minimum

Maximum

-20°F (-29°C)

120°F (49°C)

Important

Manitowoc remote systems are only approved and
warranted as a complete new package. Warranty on
the refrigeration system will be void if a new ice
machine head section is connected to pre-existing
(used) tubing or remote condensers.

IMPORTANT

EPA CERTIFIED TECHNICIANS

If remote line set length is between 50' and 100' (15.25-
30.5 m), add

additional

refrigerant to the nameplate charge.

Refer to the Installation Instructions in Installation Use and
Care Manual for the model being worked on.

Tubing length: ______________________________

Refrigerant added to nameplate: ________________

New total refrigerant charge: ___________________

!

Warning

Potential Personal Injury Situation

The ice machine contains refrigerant charge.
Installation of the line sets must be performed by a
properly trained and EPA certified refrigeration
technician aware of the dangers of dealing with
refrigerant
charged equipment.

! Caution

Never add more than nameplate charge to the
refrigeration system for any application.

Ice Machine

Nameplate Charge

(Charge Shipped in Ice Machine)

Refrigerant to be Added for

50'-100' Line Sets

Maximum System Charge

(Never Exceed)

S500

6 lb. (96 oz.)

1.5 lb. (24 oz.)

7.5 lb. (120 oz.)

S600

6.5 lb.(104 oz)

1.5 lb. (24 oz.)

8 lb. (128 oz.)

S850

8.5 lb. (136 oz.)

2 lb. (32 oz.)

10.5 lb. (168 oz.)

S1000

8.5 lb. (136 oz.)

2 lb. (32 oz.)

10.5 lb. (168 oz.)

S1400

11 lb. (176 oz.)

2 lb. (32 oz.)

13 lb. (208 oz.)

S1600

11.5 lb (184 oz.)

2 lb. (32 oz.)

13.5 lb. (216 oz.)

S1800

12.5 lb. (200 oz.)

1 lb. (16 oz.)

13.5 lb. (216 oz.)
