Memory Maps
MVME197LE/D2 3-23
3
Table 3-11. 53C710 SCSI Memory Map
N
ote
Accesses may be 8-bit or 32-bit, but not 16-bit.
Table 3-12. MK48T08 BBRAM, TOD Clock Memory Map
53C710 Register Address Map Base Address is $FFF47000
Big SCRIPTs Mode
Endian and Little
Mode Endian Mode
00 SIEN SDID SCNTL1 SCNTL0 00
04 SOCL SODL SXFER SCID 04
08 SBCL SBDL SIDL SFBR 08
0C SSTAT2 SSTAT1 SSTAT0 DSTAT 0C
10 DSA 10
14 CTEST3 CTEST2 CTEST1 CTEST0 14
18 CTEST7 CTEST6 CTEST5 CTEST4 18
1C TEMP 1C
20 LCRC CTEST8 ISTAT DFIFO 20
24 DCMD DBC 24
28 DNAD 28
2C DSP 2C
30 DSPS 30
34 SCRATCH 34
38 DCNTL DWT DIEN DMODE 38
3C ADDER 3C
Address Range Description Size (Bytes)
$FFFC0000 - $FFFC0FFF User Area 4096
$FFFC1000 - $FFFC10FF Networking Area 256
$FFFC1100 - $FFFC16F7 Operating System Area 1528
$FFFC16F8 - $FFFC1EF7 Debugger Area 2048
$FFFC1EF8 - $FFFC1FF7 Configuration Area 256
$FFFC1FF8 - $FFFC1FFF TOD Clock 8
