Memory Maps
MVME197LE/D2 3-9
3
Table 3-5. DCAM (I
2
C) Register Memory Map
DCAM (I
2
C) Base Address = $C0 (default)
Offset
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
00 00 ID Register
01 01 Version Register
02 02 SL31 SL30 SL29 SL28 SL27 SL26 SL25 DISRAM
03 03 SH31 SH30 SH29 SH28 SH27 SH26 SH25 SCRUB1TIME
04 04 CASCLKSL CASCLK2 CASCLK1 PGMODE ONEBANK DRAMSIZ3 DRAMSIZ2 DRAMSIZ1
05 05 REF7 REF6 REF5 REF4 REF3 REF2 REF1 REF0
06 06 REFTAIL4 REFTAIL3 REFTAIL2 REFTAIL1 REF11 REF10 REF9 REF8
07 07 NOT USED NOT USED RDTAIL5 RDTAIL4 RDTAIL3 RDTAIL2 RDTAIL1 RTCLKSL
08 08 READACK7 READACK6 READACK5 READACK4 READACK3 READACK2 READACK1 INTRRUPT
09 09 NOT USED READOE6 READOE5 READOE4 READOE3 READOE2 READOE1 NOT USED
0A 10 FECCKSL BREADOE6 BREADOE5 BREADOE4 BREADOE3 BREADOE2 BREADOE1 PCGCLKSL
0B 11 PCHG7 PCHG6 PCHG5 PCHG4 PCHG3 PCHG2 PCHG1 PCHG0
0C 12 SLECDM5 SLECDM4 SLECDM3 SLECDM2 FLECDM4 FLECDM3 FLECDM2 FLECDM1
0D 13 NOT USED ERAMOE6 ERAMOE5 ERAMOE4 ERAMOE3 ERAMOE2 ERAMOE1 ROECLKSL
0D 14 NOT USED RMWRMOE6 RMWRMOE5 RMWRMOE4 RMWRMOE3 RMWRMOE2 RMWRMOE1 RMWOE5
0F 15 CSRTAIL7 CSRTAIL6 CSRTAIL5 CSRTAIL4 CSRTAIL3 CSRTAIL2 CSRTAIL1 NOT USED
10 16 BWRTTL4 BWRTTL3 BWRTTL2 BWRTTL1 RMWOE4 RMWOE3 RMWOE2 RMWOE1
11 17 SECCLKSL RMWOCKSL BWRITE5 BWRITE4 BWRITE3 BWRITE2 BWRITE1 WRCLKSEL
12 18 NOT USED NOT USED RMW5 RMW4 RMW3 RMW2 RMW1 NOT USED
13 19 RMWTAIL7 RMWTAIL6 RMWTAIL5 RMWTAIL4 RMWTAIL3 RMWTAIL2 RMWTAIL1 RMWTLCSL
14 20 CBRDOE3 CBRDOE2 CBRDOE1 NOT USED CREADOE3 CREADOE2 CREADOE1 BWRTCSL
15 21 SC9 SC8 SC7 SC6 SC5 SC4 SC3 SC2
16 22 SC17 SC16 SC15 SC14 SC13 SC12 SC11 SC10
17 23 SC25 SC24 SC23 SC22 SC21 SC20 SC19 SC18
18 24 NOT USED SC32 SC31 SC30 SC29 SC28 SC27 SC26
19 25 NOT USED NOT USED NOT USED CBTAIL4 CBTAIL3 CBTAIL2 CBTAIL1 CBTLCKSL
1A 26 CSR7 CSR6 CSR5 CSR4 NOT USED NOT USED NOT USED NOT USED
1B 27 CSR15 CSR14 CSR13 CSR12 CSR11 CSR10 CSR9 CSR8
1C 28 CSR23 CSR22 CSR21 CSR20 CSR19 CSR18 CSR17 CSR16
1D 29 CSR31 CSR30 CSR29 CSR28 CSR27 CSR26 CSR25 CSR24
1E 30 NOT USED NOT USED BRDTAIL5 BRDTAIL4 BRDTAIL3 BRDTAIL2 BRDTAIL1 NOT USED
1F 31
BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
DCAM registers are only accessible/addressable on the DRAM sub-system I 2 Cbus through
the ECDM I 2 C interface.
