Installation Instructions
MVME197LE/D2 2-7
2
MVME197LE Module Installation
Now that the MVME197LE module is ready for installation, proceed as
follows:
a. Turn all equipment power OFF and disconnect the power cable from the
power source.
C
aution
Inserting or removing modules while power is applied
could result in damage to module components.
!
WARNING
DANGEROUS VOLTAGES, CAPABLE OF CAUSING
DEATH, ARE PRESENT IN THIS EQUIPMENT. USE
EXTREME CAUTION WHEN HANDLING, TESTING,
AND ADJUSTING.
b. Remove the chassis cover as instructed in the equipment user’s manual.
c. Remove the filler panel(s) from the appropriate card slot(s) at the front and
rear of the chassis (if the chassis has a rear card cage). The MVME197LE
module requires power from both P1 and P2. It may be installed in any
double-height unused card slot, if it is not configured as the system
controller. If the MVME197LE is configured as the system controller, it
must be installed in the left-most card slot (slot 1) to correctly initiate the
bus-grant daisy-chain and to have proper operation of the IACK-daisy-
chain driver. The MVME197LE is to be installed in the front of the chassis
and the MVME712X transition board which has a double-wide front panel
is to be installed in the rear of the chassis.
d. Carefully slide the MVME197LE module into the card slot. Be sure the
module is seated properly into the P1 and P2 connectors on the backplane.
Do not damage or bend connector pins. Fasten the module in the chassis
with screws provided, making good contact with the transverse mounting
rails to minimize RFI emissions.
e. Remove the IACK and BG jumpers from the header on the chassis
backplane for the card slot in which the MVME197LE is installed.
f. Connect the P2 Adapter Board and specified cable(s) to the MVME197LE
at P2 on the backplane at the MVME197LE slot, to mate with (optional)
terminals or other peripherals at the EIA-232-D serial ports, parallel port,
SCSI ports, and LAN Ethernet port. Refer to the manuals listed in the
Related Documentation section for information on installing the P2 Adapter
Board and the MVME712X transition module. (Some connection diagrams
