To avoid risk of electrical shock, personal injury or
death; disconnect power to unit before servicing.
Disassembly Procedures
WARNING
!
Front Panel Removal
1. Disconnect power supply to unit.
2. Remove Top Cover.
3. Remove Console.
4. Open door and remove Boot Retainer Clamp. Expand
the Boot Clamp Spring located at the 6 o’clock
position.
5. Pull the boot from the lip formed into the front
opening.
6. Remove four screws attaching the front to the
cabinet.
7. Disconnect the wire connectors to the Door Lock.
