Configuring the 802.11b/g and IP Settings 2-3
S e t t i n g U p U s i n g D i r e c t S e r i a l C o n n e c t i o n s
1. Disconnect the printer’s radio cable from the printer’s serial port.
2. Connect a serial cable (DB9 female to DB9 female all lines wired straight
through) from the host or computer to the print server’s radio cable.
3. Turn on the printer and configure using Telnet or other communications
program.
4. Connect the printer’s radio cable to the printer’s serial port.
5. Turn off the printer, wait a few seconds, and then turn on the printer.
Your printer is ready to use.
Radio Cable
Radio Cable
Serial Port
