DX USER IP
65
Appendix C : Pin assig nments
VGA HD-15
5
4
3
2
1
10
9
8
7
6
11
12
13
14
15
5
4
3
2
1
5
4
3
2
1
10
9
8
7
6
10
9
8
7
6
11
12
13
14
15
11
12
13
14
15
Pin
Assignment
Pin
Assignment
1
Red
9
5 V
2
Green
10
GND sync
3
Blue
11
Not connected
4
Not connected
12
SDA, DCC, ...
5
GND
13
HSYNC
6
GND red
14
VSYNC
7
GND green
15
DATA CLOCK
8
GND blue
RJ 45 Connector Ethernet
1
8
Pin
Assignment
Pin
Assignment
1
TX +
5
Not connected
2
TX -
6
RX -
3
RX +
7
Not connected
4
Not connected
8
Not connected
