Appendix A : DX U s er IP Vid eo mod es
The DX User IP supports the following video modes. Do not use other custom video
settings.
Resolution
Refresh rates (Hz)
640x350
70, 85
640x400
56, 70, 85
640x480
60, 67, 72, 75, 85, 90, 100, 120
720x400
70, 85
800x600
56, 60, 70, 72, 75, 85, 90, 100
832x624
75
1024x768
60, 70, 72, 75, 85, 90, 100
1152x864
75
1152x870
75
1152x900
66, 76
1280x960
60
1280x1024
60
1280x1024
75
1600x1200
60
