Appendix B
B-1
Appendix B:
Example Setting User Parameters
For user parameters, refer to chapter 6.
B-1 Example Configuration User Parameters
B-1-1 Example Setting for FX 2N -4AD
For BFM’s definition, refer to FX
2N
-4AD User’s Manual.
Table B-1: User Parameter FX
2N
-4AD
Using GSD File
User
Parameter
Type
Description
Using Programming Tool
Byte No.
Setting
Value
(Hex)
Register
No.
Setting
Value
(Hex)
Higher/
Lower
Byte
0 00 H User
parameter
for 32DP-IF
See section 6.1. D200 0000 H
Lower
1 00 H Higher
2 DA H
User
parameter
for special
function
block
(FX
2N
-4AD)
BFM #30 lower byte: “DA H”
D201 07DA H
Lower
3 07 H BFM #30 higher byte: “07 H” Higher
4 09 H
Total length of parameter bytes for this
special function block is 9 bytes (byte
No. 4 ~ 12).
D202 0409 H
Lower
5 04 H
Example: number of BFM for data
exchanged every cycle is 4
BFMs (BFM #9 ~ #12). Higher
6 09 H Specified exchange, ex. BFM #9
D203 0A09 H
Lower
7 0A H Specified exchange, ex. BFM #10 Higher
8 0B H Specified exchange, ex. BFM #11
D204 0C0B H
Lower
9 0C H Specified exchange, ex. BFM #12 Higher
10 80 H
Example: If BFM #0 is set to “1100 H”.
Ch 1: Voltage input mode
Ch 2: Voltage input mode
Ch 3: Current input mode
(4~20 mA)
Ch 4: Current input mode
(4~20 mA)
D205 0080 H
Lower
11 00 H BFM #0 lower byte = “00 H” (ch 1, ch 2) Higher
12 00 H BFM #0 higher byte = “11 H” (ch 3, ch 4)
D206 0011 H
Lower
- - - Higher
FX2N-32DP-IF Profibus-DP Interface Units
