KHLDV Series Gas Fireplace
repLaceMent partS
SIGnature cOMManD SySteM
Item
Description
qty. KHLDV400ntSc KHLDV400ptSc KHLDV500ntSc KHLDV500ptSc
1.
Gas Valve Assembly
1
80D0001
80D0002
80D0001
80D0002
2.
Pilot Assembly
1
80D0039
80D0040
80D0039
80D0040
3.
Control Box
1
80D0037
80D0038
80D0037
80D0038
4.
Command Center
1
80D0005
80D0005
80D0005
80D0005
5.
Tube, Rear, Venturi
1
73D349K
73D3549K
54D0564
54D0564
5.
Tube, Front, Venturi
1
73D0562K
73D0562K
43D0185
43D1085
5.
Rear Tube, Tee to Solenoid
1
73D3529K
73D3529K
73D3529K
73D3529K
5.
Rear Tube, Solenoid to Venturi
1
73D3528K
73D3528K
73D3528K
73D3528K
5.
Tube, Front, Through-wall
1
73D0146K
73D0146K
73D0146
73D0146
6.
Flexhose w/Shutoff Valve
1
69D0030
69D0030
69D0030
69D0030
7.
Rear Injector
1
38D0102
38D0102
57D0679
57D0680
7.
Front Injector
1
57D0612
57D0612
56D3059
62D3005
8.
Rear Burner Assembly
1
73D3270
73D3270
73D3268
73D3268
8.
Front Burner Assembly
1
73D3269
73D3269
73D3267
73D3267
9.
Venturi
1
45D0600
45D0600
45D0600
45D0600
10.
Wire Valve/Control (not shown)
1
80D0010
80D0010
80D0010
80D0010
11.
Wire AC Module (not shown)
1
80D0009
80D0009
80D0009
80D0009
12
Wire Command Ctr. (not shown)
1
80D0008
80D0008
80D0008
80D0008
13.
Remote Transmitter (full function) 1
RFSC
RFSC
RFSC
RFSC
14.
AC Module
1
SCSACM
SCSACM
SCSACM
SCSACM
15.
Solenoid (not shown)
1
73D3007
73D3007
73D3007
73D3007
accessories
16.
Forged Andiron 13"
1
FA113
FA113
FA113
FA113
17.
Cast Iron 12
1
/
2
"
1
CAI121/2
CAI121/2
CAI121/2
CAI121/2
Fuel conversion Kits - Signature command System
natural Gas to Lp
KHLDV400
Kit #KHL400CKPS
KHLDV500
Kit #KHL500CKPS
Lp to natural Gas
KHLDV400
Kit #KHL400CKNS
KHLDV500
Kit #KHL500CKNS
