Multiquip TRASH PUMP (hatz 1B40u-2203a diesel engine) Qp4tZt10p - Manual (Page 97)

qp4TzT10p/TMp16F/TMpXF Trash puMp • operaTion & parTs Manual — rev. #1 (08/29/11) — page 97
hatZ 1B40u-2203a — air ducting assy. (a)
AIR DUCTING ASSY. (A)
no. parT no. parT naMe qTY. reMarKs
G 50256501 LOCTITE IS407 20G 1
1 01853100 HOOD ASSY ......................................................1................INCLUDES ITEM W/ #
2# HOOD ................................................................1................NOT SOLD SEPARATELY
3# 05152100 SPRING CLIP 1
4 01345400 COOLING AIR DUCT ASSY ..............................1................INCLUDES ITEM W/ $
5$ AIR DUCT ..........................................................1................NOT SOLD SEPARATELY
6$ 04144200 SEALING STRIP 119MM 1
8$ 50334800 RUBBER SLEEVE 1
9 50445401 FILL.HEAD SCREW M4X10 4
10 50441600 WASHER 4.3 4
11 50163801 RUBBER SLEEVE 4
12 50528100 ALLEN SCREW M6X16 3
13 01345300 COOLING AIR DUCT ASSY ..............................1................INCLUDES ITEMS W/ %
14% AIR DUCT ..........................................................1................NOT SOLD SEPARATELY
15% 04144200 SEALING STRIP 119MM 1
16 50495000 SCREW M6X12 1
17 50144400 HEXAGON NUT M6 2
18 50170900 SPRING WASHER 6 2
19 03354600 SPACER BUSH 2
20 01698200 COVER 1
21 50334800 RUBBER SLEEVE 1
22 03577200 SEALING STRIP 1
23 50144500 FLAT WASHER 6.4 2
24 04060600 WASHER 6.4X16X1.5 1
25 05001200 CLIP 1
1
2
18
19
17
21
22
20
11
8
6
10
16
4
9
25
10
12
11
9
23
13
24 15 12
12
23
G
SEALING AND BONDING
ADHESIVES
Parts not available separately
