qp4TzT10p/TMp16F/TMpXF Trash puMp • operaTion & parTs Manual — rev. #1 (08/29/11) — page 89
hatZ 1B40u-2203a — tiMing cOver assy.
TIMING COVER ASSY.
no. parT no. parT naMe qTY. reMarKs
D 50223300 LOCTITE221 50ML 1
E 50223400 LOCTITE648 10ML 1
H 50282501 SILICON 30ML 1
K 50342601 HOCHTEMP.FETT 400G 1
1 01894200 TIMING COVER CP. ASSY ..........................................1 ................. INCLUDES ITEMS W/ #
2# TIMING COVER ...........................................................1 ................. NOT SOLD SEPARATELY
3# 04185800 CLOSING PLUG 1
4# 50464100 O-RING 2X1 1
5# 04185700 CLOSING PLUG 4X15 1
6# 04168600 PLUG 4.3 1
7# 01344600 BOLT F.GOV.HOUSING 1
8# 04148800 MAIN BEARING 1
9# 50530600 GRUB SCREW M8X10 4
10# 50479500 OIL SEAL 35X47X7 1
11# 50400600 GRUB SCREW M 5X10 2
12 03794201 CAM FOLLOW SP. 2
13 50469900 ALLEN SCREW M6X30 2
15# 01346710 ROCKER LEVER ASSY ...............................................1 ................. INCLUDES ITEMS W/ $
16$ ROCKER LEVER .........................................................1 ................. NOT SOLD SEPARATELY
17$ BUSHING, ROCKER LEVER .......................................1 ................. NOT SOLD SEPARATELY
18$ PIN, ROCKER LEVER .................................................1 ................. NOT SOLD SEPARATELY
19$ PIN, ROCKER LEVER .................................................1 ................. NOT SOLD SEPARATELY
20$ CLAMP, ROCKER LEVER ............................................1 ................. NOT SOLD SEPARATELY
21$ CLAMP, ROCKER LEVER ............................................1 ................. NOT SOLD SEPARATELY
22$ SPINDLE ......................................................................1 ................. NOT SOLD SEPARATELY
24# 50561800 CTR.SUNK SCREW M6X40 1
25 04094700 DRAW ROD 1
26 04095700 PRESSURE SPRING 1
27 04133900 DISC 10.7X19X0.5 1
28 04094802 CUP 1
29 05095210 SPRING F.GOVERNOR 1
30 50499300 GRUB SCREW M6X35 1
31 50144400 HEXAGON NUT M6 1
32 50499400 GRUB SCREW M4X25 1
33 50384200 ALLEN SCREW M6X12 1
34 04095210 COVER 1
35 50463000 ALLEN SCREW M8X130 2
36 50162900 JOINT A8X14 2
37 50459100 JOINT A22X27 1
38 50373100 DRAIN PLG.MAGNT.M22 1
39 50397100 ALLEN SCREW M4X10 4
40 01351700 COVER 1
41 50329000 O-RING 9.5X2.5 1
42 50095100 SPRING WASHER A8 15
43 50288800 ALLEN SCREW M8X55 11
44 50177500 ALLEN SCREW M8X40 2
45 50392900 ALLEN SCREW M8X50 2
46 03794100 WASHER 2
47 04146600 CAM FOLLOWER 1
48 04146000 CAM FOLLOWER 1
49 05127100 LEVER 1
51# 50262400 THREADED PIN M6X10 1
53 04189500 CUP 1
13
46
12
48
46
12
42
13
47
6
45
1
42
5 7
4
3
51
42
10
11
44 43
36
37
38
40
41
9
39
49
34
35
32
33
31
30
27
28
24
26
29
53
8
25
15
D E H K
Parts not available separately
