qp4TzT10p/TMp16F/TMpXF Trash puMp • operaTion & parTs Manual — rev. #1 (08/29/11) — page 71
puMp and Battery assy. (Qp4tZt10p)
no. parT no. parT naMe qTY. reMarKs
1 14712140200014 ENGINE BASE, SS400 1
2 0105051040 BOLT (PUMP), M10 X 40 2
3 0451250100 WASHER, LOCK M10 6
4 0205450100 NUT, M10 8
5 0723302546 CUSHION RUBBER 4
6 29175 BRACKET, CHANNEL 2
7 6109184 BOLT, HEX 1/2-13 X 2-1/2 4
8 6109170 WASHER, FLAT 1/2" 8
9 6109180 WASHER, LOCK 1/2" 4
10 6109160 NUT, HEX 1/2-13 4
11 1B40U-2203A ENGINE, HATZ 1
12 09592250000014 COVER, BATTERY 1
13 0950241265AP002 BOLT WITH NUT, BATTERY 2
14 0451250080 SPRING WASHER, BATTERY 2
15 0401450080 WASHER, BATTERY 2
16 0975209300 NEGATIVE BATTERY CABLE 1
17 0976209450 POSITIVE BATTERY CABLE 1
