Multiquip TRASH PUMP (hatz 1B40u-2203a diesel engine) Qp4tZt10p - Manual (Page 75)

qp4TzT10p/TMp16F/TMpXF Trash puMp • operaTion & parTs Manual — rev. #1 (08/29/11) — page 75
hatZ 1B40u-2203a — crankcase kit
32
33
14
15
10
11
20
19
21
31
8
7
13
9
30
30
31
5
6
4
26
5
25
24
27
29
26 36
23
37
38
21
1
17
16
19
20
22
D H
SEALING AND BONDING
ADHESIVES
Parts not available separately
CRANKCASE KIT
no. parT no. parT naMe qTY. reMarKs
D 50223300 LOCTITE221 50ML 1
H 50282501 SILICON 30ML 1
1 01679100 CRANKCASE ASSY ..........................................1................INCLUDES ITEMS W/ #
2# CRANKCASE .....................................................1................NOT SOLD SEPARATELY
3# PLUG .................................................................1................NOT SOLD SEPARATELY
4# 04141600 COVER SHEET 1
5# 40002600 BLIND RIVET3.2 1
6# 01336400 COVER SHEET (SIDE) 4
7# 50502801 CYL.PIN M6X24 1
8# 50440300 O-RING 8X1.5 1
9# 50249102 CYL.PIN M6X24 1
10# 50062400 JOINT A10X13.5 1
11# 50062300 CLOS.SCREW M10X1 1
12# PLUG .................................................................1................NOT SOLD SEPARATELY
13# 40022300 O-RING 8X2 1
14 50479000 OIL SEAL 45X60X8 1
15 04144401 GRUB SCREW 1
16 01342800 DIPSTICK ASSY ................................................1................INCLUDES ITEMS W/ $
17$ 04125000 SEALING RING 1
18$ DIPSTICK ..........................................................1................NOT SOLD SEPARATELY
19 50208500 SPRING WASHER 8 8
20 04219500 ALLEN SCREW M8X40 8
21 04144701 ENGINE BRACKET 4
22 04141500 TUBE F.OIL FILTER 1
23 01542702 OIL SUCTION FILTER ASSY ............................1................INCLUDES ITEMS W/%
24 50373100 DRAIN PLG.MAGNT.M22 1
25 50001600 JOINT A22X27 1
26 05036900 HOSE CLIP 2
27 04163000 T-PIECE 1
29 50478900 GROOV.BALLBEAR.6310 1
30 04133800 PLATE 3
31 50564200 ALLEN SCREW M6X18 6
32 01555800 COVER 1
33 03568701 OIL SUPPLEMENT PLUG 1
35% FILTER, OIL SUCTION ......................................1................NOT SOLD SEPARATELY
36% 50475901 O-RING 20X4 1
37% 05148200 PLATE SPRING 2
38% 50170700 ALLEN SCREW M6X16 1
