6 33D4047
NATURAL GAS
Manual and T-Stat Pressure
Regulator Pressure Setting 4 in. w.c.
Gas Inlet Pressure: Max. 10.5 in. w.c.
Min. 5 in. w.c.
PRODUCT FEATURES and SPECIFICATIONS
IGNITION CONTROLS
Piezo ignitor allows ignition of the pilot without the use of matches or batteries.
Manual control has four (4) positions:
OFF
- All gas to the gas logs is shut off at the valve.
IGN - Valve position to light/maintain a standing pilot.
ON -
Valve position to turn ON/OFF log set with remote switch/thermostat.
LOW/HI - Variable position to control flame height (heat output). Both front and rear burners are in operation to
provide realistic glow and yellow flame.
Thermostat control has three (3) positions:
OFF - All gas to the gas logs is shut off at the valve.
IGN - Valve position to light/maintain a standing pilot.
LOW/HI - Variable position corresponding to desired temperature.
Continued
Model Number Type
Gas Rate Number of
Burners Max BTU/Hr Min BTU/Hr
DFX24PMC Manual 22,000 17,000 1
DFX24PVC Milli-Volt 22,000 17,000 1
DFX32PMC Manual 26,000 15,000 1
DFX32PVC Milli-Volt 26,000 20,000 1
DBX24PTC T-Stat 10,000 — 1
Milli-Volt Pressure
Regulator Pressure Setting 3.5 in. w.c.
Pilot Regulator 3.5 in. w.c.
Gas Inlet Pressure: Max. 10.5 in. w.c.
Min. 5 in. w.c.
PROPANE / LPG
Note: An external regulator is required to reduce supply pressure to a maximum of 13" w. c.
T-Stat, Manual and Milli-Volt Pressure
Regulator Pressure Setting 10 in. w.c.
Gas Inlet Pressure: Maximum 13 in." w.c.
Minimum 11 in. w.c.
Model Number Type
Gas Rate Number of
Burners Max BTU/Hr Min BTU/Hr
DFX24NMC Manual 22,000 15,000 1
DFX24NVC Milli-Volt 22,000 17,000 1
DFX32NMC Manual 26,000 15,000 1
DFX32NVC Milli-Volt 26,000 20,000 1
DBX24NTC T-Stat 10,000 — 1
