Monessen Hearth Vent-Free Fireplace Systems DBX24C* - Manual (Page 39)

33D4047 39
REPLACEMENT PARTS LIST
REPLACEMENT PARTS ARE AVAILABLE THROUGH YOUR RETAILER.
ITEM DESCRIPTION QTY
DFX32C MILLIVOLT DFX32C MANUAL
NATURAL PROPANE NATURAL PROPANE
1 Burner/Grate Assembly 1 33D5050 33D5050 33D5050 33D5050
2 Injector 1 33D5040 33D5039 33D5040 33D5039
3 Venturi 1 58D0454 33D4058 58D0454 33D4058
4 Control Knob 1 — — 18D0603 18D0603
5 Milli-Volt Valve 1 14D0467 14D0468 — —
5 Manual Control Valve 1 — — 30D0201 30D0202
6 Pressure Valve Regulator 1 14D0469 — 24D0305 24D0306
7 Burner to Valve Tube 1 33D5511 33D5511 33D5512 33D5512
8 Tube Fitting, 3/8 x 5/16 1 11V0313 11V0313 11V0313 11V0313
9 Regulator Valve Tube, 5/16 — — 33D4512 33D4512
10 ODS Pilot Valve Tube, 3/16 1 49D0050 49D0050 49D0050 49D0050
11 Piezo Ignitor 1 14D0503 14D0503 14D0503 14D0503
12 Piezo Wire 1 00K0632 00K0632 00K0632 00K0632
13 ODS Pilot Assembly 1 14D0473 14D0477 26D2529 14D0476
LOG SET
14 #1 Right Front Log 1 33D5042 33D5042 33D5042 33D5042
15 #2 Left Front Log 1 33D5043 33D5043 33D5043 33D5043
16 #3 Rear Log 1 33D5044 33D5044 33D5044 33D5044
17 #4 Right Middle Log 1 33D5045 33D5045 33D5045 33D5045
18 #5 Left Middle Log 1 33D5046 33D5046 33D5046 33D5046
PARTS AVAILABLE, NOT SHOWN
Tube Nut, 3/16 1 — — 00F0077 00F0077
Tube Ferrule, 3/16 1 — — 00F0078 00F0078
Tube Nut, 5/16 1 00K0917 00K0917 — —
Tube Nut, 5/16 3 — — 00K0917 00K0917
Tube Ferrule, 5/16 1 00K0918 00K0918 — —
Tube Ferrule, 5/16 3 — — 00K0918 00K0918
Flex Tube with Fittings 1 20H0022 20H0022 20H0022 20H0022
10 Grams Rock Wool Bag 1 70D0129 70D0129 70D0129 70D0129
