5320 IP Phone – User Guide
5320 IP Phone Default Window and Keys
Feature Function
1) Softkeys Allow you to access specific call control features, which are context sensitive.
Non-programmable feature keys, which are specific to the application or state of
the set. The 5320 provides three softkeys.
2) Programmable Keys Launch specific call control features. Use the Settings application or the UC
Express application to program these keys. The 5320 provides 7 programmable
keys plus 1 prime line key. For instructions on programming the keys, see
Programming Features on Your Keys .
3) Navigation Page Keys Display additional pages of information. The 5320 has two page navigation keys:
Back and Next.
4) Status Line Displays time, date, and icons indicating feature states as follows:
 Message Waiting ( ) - Indicates new voice mail.
 Headset ( ) - Indicates that the phone is in headset mode.
 DND ( ) - Indicates DND (Do not disturb) mode.
 Logged in as ( ) - Indicates that a hot desk user is logged in.
5) Information Area Provides prompts in most phone applications. Content changes based on the
application.
6) Footer Shows context and summary information based on information in the
Programmable Keys area, such as Page Indicators, numbers of items, and so
forth.
- 6 -
