Maxtor WDR-516S - Manual (Page 17)

WDR-516S Installation Guide 17 Rev 1.0(93/11)
(3) Select “Miscellaneous” from the sub-menu list using the [▼] button and press the [ENETR] button.
(4) Select “Remote Control ID,” and press the [ENETR] button.
(5) Select a value using the [◄ or ►] buttons and press the [EXIT] button.
(6) Press the [EXIT] button to exit the Settings Page and return to Monitor mode.
Remote Control ID
Up to 16 WDRs can be controlled with a single remote controller.
6.3. Selecting WDR-516S
If several WDRs are set with unique ID numbers, they can be controlled with one remote controller. To
select a specific WDR-516S, press the ID button of remote controller until the 8 LEDs on the front of the
WDR-516S light up and a buzzer sounds.
Because remote controller ID is sixteen, WDR will correspond.
PWR NET REC PLAY
A1 A2 A3 A4
Unselected
Selected
PWR NET REC PLAY
A1 A2 A3 A4
All LED Blink One Time
Press repeatedly
till to select WDR
What you want
Remote Controller
