NOTE: Fasten the Velcro™ tab to prevent the zipper from re-
opening.
ZIP 2 - Close by pulling slider in the opposite direction to the end the
zipper (Fig. 36). Ensure that the Inflatable cell does not get caught by
the zipper when closing.
\
FIGURE 35 FIGURE 36
12) Tuck in the zipper tail, so it is not exposed (Fig. 37).
Zipper
Tail
FIGURE 37
13) The right lobe should now be fastened closed and the inflator should
be visible through the clear window. Ensure the beaded handle is
placed through the opening and is attached to the Velcro tab on the
outside of the vest (Fig. 39). Ensure the zipper is closed to the stop,
located under the Velcro tab.
NOTE: Ensure the chest buckle does not extend outside of the
Inflatable Vest with LIFT
TM
Owner’s Manual 22
