Mustang Survival MD0450 22 User Manual
Page 24
Velcro
TM
Tab
FIGURE 32
10) Mustang Survival uses advanced 2-step zippers -
SecureZIP
TM
. Find
the right zipper tail on the right lobe and ZIP 1 -
Reset the 2-step
zipper by pulling the slider to the Velcro™ tab (Figs. 33 and 34).
NOTE: Fasten the Velcro™ tab to prevent the zipper from re-
opening.
ZIP 2 - Close by pulling slider in the opposite direction to the end the
zipper (Fig. 34). Ensure that the Inflatable cell does not get caught by
the zipper when closing.
\
FIGURE 33
FIGURE 34
11) Find the left zipper tail on the right lobe and ZIP 1 - Reset the 2-
step zipper by pulling the slider to the Velcro™ tab (Fig. 35).
21
MUSTANG SURVIVAL
