Page 10
firmly downward. The PFD should fully inflate within 5 seconds (Fig.
6).
NOTE: Deflation may occur if the CO
2
cylinder is removed
while the Inflatable Vest with LIFT
TM
is inflated.
FIGURE 6
2) Fasten the chest straps (Fig. 7) and adjust to a snug fit.
Important: Ensure the chest buckle is fastened, when inflated.
Fastened
Chest Strap
FIGURE 7
Automatic Backup Inflation
Inflation will occur automatically within 5 seconds after the inflator is
immersed in water. Hydrostatic pressure opens the water inlet valve
allowing the water-sensing element to disintegrate, triggering a spring-
loaded plunger, which punctures the CO
2
cylinder inflating the Inflatable
Vest with LIFT
TM
(Fig. 7).
7
MUSTANG SURVIVAL
