Mustang Survival MD0450 22 User Manual
Page 22
4) Lay out flat the right lobe (as it is worn). Shift the left lobe (as it is
worn) on the waist belt to fully extend the right lobe for folding.
NOTE: The numbered fold lines, on the diagram, are provided
to assist with packing. Make each fold towards yourself.
5) Fold the right lobe (as it is worn) over on the Fold #1 dashed line
(Fig. 28). Note that the right lobe has the inflator with cylinder.
FOLD #3
FOLD #2
Right Lobe
FIGURE 28
6) Continuing with the right lobe, fold it over on the Fold #2 dashed
line (Fig. 29). Ensure that the bladder is tucked under the inflator to
prevent it from blocking the indicator window (Point A).
D #3
A
FIGURE 29
19
MUSTANG SURVIVAL
