Battery Compartment

The battery compartment contains:

Item Description

1

Power connector

2

Strain-relief posts for power cord

3

Positive battery wire (red)

5

Negative battery wire (black)

5

Battery snaps

6

Back-up battery

7

Battery hook

1

2

3

4

5

6 7

For instructions to remove the battery compartment
cover, see

“Cabling and Startup for a Single User”

on

page 13.
