STEP6 - Attach Control Panel
9
STEP 7 - Attach Igniter Wire
•Attach Igniter Wire : Push electrode connector
at end of Igniter wire onto center tab on rear
of Igniter Button.
•NOTE: Be sure to route electrode wire away
from hot areas of the grill.
Confirm the valve
is inserted into the
burner venturi.
Valve
Venturi
Valve
•Insert valve tips on back of control panel into burner venturi. Secure control panel to cart using 4 M6
x 50mm Screws and 4 M6 Nuts.
Screw
M6 x 50mm
4 pcs
Nut
M6
4 pcs
