47 Axiom Pro User Guide
Parameter: PatchID
Value Range: On, Off
When this option is enabled, a “system exclusive” (SysEx) MIDI message that contains all the
settings of the selected Axiom Pro patch is sent out whenever a patch is recalled from the Load
Page
Parameter: MIDI Out
Value Range: USB, Keyboard
The MIDI Out port on the back of Axiom Pro can be configured to transmit MIDI data generated by
the Axiom Pro keyboard or from the computer via the USB connection:
• USB The MIDI output port transmits data received from your audio application via the
USB connection When this parameter is set to “USB,” the MIDI output port will
not transmit any data generated by the controls of the keyboard (i e , buttons,
knobs, keys, etc )
• Keyboard The MIDI output port will transmit the data generated by the controls of the
keyboard (i e, keys, buttons, knobs, etc ) When this parameter is set to “Keyboard,”
any data sent to Axiom Pro through the USB connection will not be transmitted
through the MIDI output port
✓ NOTE: MIDI data that is generated by the controls of Axiom Pro is always sent
to your computer through the USB connection, regardless of how this parameter
is configured. This parameter only affects the MIDI output port on the rear of
the keyboard and determines what data is transmitted through the port.
Parameter: Send All
Value Range: Send
When this parameter is selected, a “Send” option appears for Soft Key 4 Pressing this button will
send a SysEx dump of the entire memory contents of Axiom Pro out of the selected SysEx port (see
the SysEx parameter above to select a SysEx output port)
✓ TIP FOR ADvANCeD MIDI USeRS: It is also possible to trigger this function
externally This is done by sending the following SysEx message to Axiom Pro:
F0 00 01 05 20 7F 01 7F F7
