43 Axiom Pro User Guide
Edit Mode > Zones
press 4
The Edit Mode > Zones page lets you configure the parameters for each of the four zones contained within Axiom Pro
To select the range of a keyboard zone:
1 Use Soft Keys 2-3 (or Encoder Knob E1) to select the zone you would like to edit
2 Use Encoder Knob E5 to set the lowest note contained in your range 10
3 Use Encoder Knob E6 to set the highest note contained in your range 10
✓ TIP: Keyboard zone ranges can also be set by pressing the lowest and highest notes of the range on the
keyboard itself
10
4 Press Soft Key 4 (Data) to access additional parameters relating to the selected zone (the parameters contained on the
“Data” sub-menu are covered in the following section of this guide )
To activate or deactivate a zone:
The radio buttons on the left edge of the screen indicate which zones are currently active (active zones have filled in buttons
while inactive zones are not filled in) Use Slider Buttons “1” through “4” (“Loop,” “Rewind,” “Fast Forward,” and “Stop”
buttons on Axiom Pro 25), to activate a corresponding zone To activate more than one zone, press and hold multiple buttons
at the same time
To deactivate a zone, press that zone’s corresponding Slider button again
10 Note that when selecting keyboard zones, octave shift and transposition are ignored (i.e., Axiom Pro is assumed to be
in its default transposition/octave-shift range).
